负载点电源（POL）
3044永利集团创新提供的POL降压电源产品具有动态响应快、输出纹波小、效率高、支持预偏置启动、配备主动输出电容放电、差分输出电压检测、以及特色的FB管脚开路；，并提供多种封装选择等优势。
产品选择器
12 个结果
Loading
|
Part No
|
Status
|
Function
|
Supply Voltage (V) Min
|
Supply Voltage (V) Max
|
Output Current (A) Max
|
Ron (mΩ) HSFET
|
Ron (mΩ) LSFET
|
Reference Voltage (V)
|
Quiescent Current (μA)
|
Switching Frequency (MHz)
|
Note
|
Temperature Operating Range (°C)
|
Package
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MP | POL | 4.2 | 18 | 4 | 55 | 30 | 0.796 | 120 | 0.58 | COT/PFM/FCCM | -40~125 | SOT563, 1.7*1.7 | |
| MP | POL | 2.35 | 6 | 6 | 20 | 13 | 0.6 | 20 | 1.2 | COT/PFM/FCCM | -40~125 | UQFN-13, 2*3 | |
| MP | POL | 3.8 | 28 | 8 | 18 | 9 | 0.6 | 135 | 0.63 | COT/PFM/FCCM | -40~125 | UQFN-16, 2.5*2.5 | |
| MP | POL | 3 | 17 | 12 | 9 | 3.2 | 0.6 | 180 | 0.4/0.8/1.2 | COT/PFM | -40~125 | QFN-18, 3.5*3.5 | |
| MP | POL | 2.5 | 16 | 12 | 13 | 4 | 0.6 | 200 | 0.6/0.8/1.0 | COT/PFM/FCCM | -40~125 | QFN-21, 3*4 | |
| MP | POL | 2.5 | 6 | 4 | 22 | 14 | 0.4 | 20 | 2.4 | COT/PFM/FPWM | -40~125 | DFN-8, 1.6*2.1 | |
| MP | POL | 2.5 | 6 | 6 | 20 | 10 | 0.4 | 20 | 2.4 | COT/PFM/FPWM | -40~125 | DFN-8, 1.6*2.1 | |
| MP | POL | 4.2 | 18 | 5 | 45 | 25 | 0.8 | 120 | 0.58 | COT/PFM | -40~125 | DFN-6, 2*2 | |
| MP | POL | 4.5 | 18 | 8 | 21 | 10 | 0.6 | 290 | 0.6/1,2 | COT/PFM/FCCM | -40~125 | QFN-13, 2*3 | |
| MP | POL | 2.5 | 18 | 8 | 22 | 10 | 0.6 | 140 | 1.2 | COT/PFM | -40~125 | QFN-16, 3*3 | |
| MP | POL | 2.4 | 6 | 2 | 120 | 80 | 0.6 | 35 | 1.5 | COT | -40~125 | SOT563, 1.6*1.2 | |
| MP | POL | 4.2 | 18 | 5 | 45 | 25 | 0.6 | 120 | 0.56 | COT | -40~125 | QFN-6, 2*2 |
